描述
| Product Attribute | Attribute Value | Select Attribute |
|---|---|---|
| Analog Devices Inc. | ||
| Product Category: | Precision Amplifiers | |
| RoHS: | ||
| 2 Channel | ||
| 800 kHz | ||
| 150 mV/us | ||
| 100 uV | ||
| 250 pA | ||
| +/- 18 V | ||
| +/- 2 V | ||
| 800 uA | ||
| 15 mA | ||
| 110 dB | ||
| 17 nV/sqrt Hz | ||
| SOIC-8 | ||
| SMD/SMT | ||
| No Shutdown | ||
| – 40 C | ||
| + 85 C | ||
| AD706 | ||
| Reel | ||
| Cut Tape | ||
| MouseReel | ||
| Brand: | Analog Devices | |
| Dual Supply Voltage: | +/- 15 V | |
| Height: | 1.5 mm (Max) | |
| Length: | 5 mm (Max) | |
| Maximum Dual Supply Voltage: | +/- 18 V | |
| Minimum Dual Supply Voltage: | +/- 2 V | |
| Operating Supply Voltage: | 4 V to 36 V | |
| Pd – Power Dissipation: | 650 mW | |
| Product: | Precision Amplifiers | |
| Product Type: | Precision Amplifiers | |
| PSRR – Power Supply Rejection Ratio: | 110 dB | |
| 1000 | ||
| Subcategory: | Amplifier ICs | |
| Type: | General Purpose Amplifier | |
| Voltage Gain dB: | 126.02 dB | |
| Width: | 4 mm (Max) | |
| Unit Weight: | 0.019048 oz |
